Mastercard Gateway
Explore our guides and examples to integrate Mastercard Gateway.
Mastercard Gateway

Magento 2
Online payments for Magento 2

OpenCart
Online payments for OpenCart

PrestaShop
Online payments for PrestaShop
Explainer Videos


Install the Mastercard Gateway plugin and configure it in the WooCommerce admin panel.
Transcript
Hi, welcome to Mastercard Gateway, your portal to effortless payment integration. Today, we’ll guide you through the quick and easy installation and configuration of the WooCommerce Mastercard Plugin. First, you’ll need to download the WooCommerce MasterCard Module directly from Fingent's GitHub repository. Before installing or uninstalling, make sure the necessary module permissions are enabled. For example, you can use the command: chmod 777 -R /wp-content/plugins Chmod 777 -R /wp-content/upgrade Here, 777 is just a placeholder. You should set permissions based on your specific requirements.
To install the WooCommerce Mastercard plugin using Fingent's GitHub repository, navigate to the following page. Scroll down to the "Releases" section and click on the version tagged as "Latest" to view the most recent release, or click on the "Releases" link to see a complete list of all available plugin versions.
Inside every version card, expand the ‘Assets’ section to see the respective version. Locate the version you want & click on the ‘woocommerce-mastercard.zip’ file to download it. Next, you'll need to upload the downloaded file to the Plugins section in your WordPress Admin panel. To do this, first login to your WordPress Admin Dashboard. In your WordPress Admin Dashboard, hover over the Plugins menu and click on Add New to begin the installation process. At the top of the Add Plugins page, click on the "Upload Plugin" button to proceed with the installation. Click on "Choose File", locate and select the downloaded ‘woocommerce-mastercard.zip’ file, then click "Install Now" to begin the installation. Once the installation is complete, click on the "Activate Plugin" button to enable WooCommerce Plugin on your platform. Alternatively, you can activate the plugin manually from the Plugins page.
Now let's explore the backend configuration settings at a glance. Simply find WooCommerce, go to settings, and navigate to the payments tab, where you can locate the ‘Mastercard Gateway’ in the list of available payment methods’. Click on Manage to enable and configure the integration method that best suits your business needs. The two available integration methods are, Hosted Checkout and Hosted Session. Hosted Checkout is a fully managed, ready-to-use payment page hosted by the payment provider, ensuring a secure and seamless transaction process.
Hosted Session gives you more control by allowing you to manage the payment experience directly within your website while maintaining security and compliance. With these two Integration Models, you can configure your payment flow by choosing between ‘Purchase’, which instantly captures and completes the payment in a single step or ‘Authorize’, which reserves the funds for later capture, giving you more control over transaction processing.
Since Hosted Checkout is the default selection for the Integration Model, let’s start by exploring its configuration. In Hosted Checkout, you have the flexibility to configure settings for both 3DS-enabled cards, which gives enhanced security with 3D Secure authentication, & Non-3DS cards used for standard payment processing. Set the Transaction Mode to "Purchase", which ensures that the customer is charged immediately upon completing the transaction.
You can also set the Transaction Mode to "Authorize", where the payment is reserved. Then, you can manually capture the payment later through the WooCommerce Admin Panel, giving you more control over transaction processing.
When using the Hosted Checkout Integration Model, you can define the Checkout Interaction method as ‘Redirect to Payment Page’, where the customers are redirected to a secure, hosted payment page to complete the transaction or ‘Embedded’, where the payment form is embedded directly within your website for a seamless checkout experience.
Choosing ‘Redirect to Payment Page’ directs customers to a secure payment page hosted by the payment provider. You’ll be able to pass on certain branding information, like the merchant’s business logo and relevant information, also to this redirected page, ensuring a branded and professional checkout experience. On your end, you’ll need to configure the merchant business logo and other relevant details under the Merchant Information section.
Simply enter the required information in the designated fields to ensure your branding appears on the payment page. Now, let’s move on to Hosted Session configuration. To set up "Purchase" mode for the three 3DS security levels 3DS-Disabled, 3DS1, and 3DS2 (with fallback to 3DS1) navigate to Hosted Session, then select "Purchase" as the Transaction Mode. To configure "Authorize" mode in Hosted Session for the three 3DS security levels, navigate to Hosted Session and select "Authorize" as the Transaction Mode. This allows you to reserve funds first and capture them later through the WooCommerce Admin Panel. Before saving your configuration, ensure that the 3D Secure option is set correctly. Disabled for 3DS-disabled cards, 3DS1 for 3DS1 security level, and 3DS2 with fallback to 3DS1 for 3DS2 enabled cards. This ensures that each transaction follows the appropriate security authentication process.
Finally, save the configuration, and that’s it! The WooCommerce Mastercard Plugin is now successfully installed and set up, ready for use.


Install the Mastercard Gateway plugin and configure it in the Magento 2 admin panel.
Transcript
Hi, welcome to Mastercard Gateway, your pathway to seamless payment integration. Here we will explore installation and configuration of the Mastercard Gateway module on your Adobe Commerce websites. You can install the Mastercard Gateway module in two ways; using Fingent’s GitHub repository or from the Adobe Commerce Marketplace.
Let’s start with the Fingent GitHub repository.
Open the following page.
Click on the ‘Code’ button and copy the clone link given inside the HTTPs textbox.
Open a terminal in MacOS or the Command Prompt in Windows machine and type the command line instructions as shown.
Then, after typing in the git clone command, paste the code snippet copied from GitHub and press Enter to kickstart the installation of the package.
To finish the installation, follow the command sequence as shown.
Now, let’s focus on the Marketplace method.
Go to the Adobe Commerce Marketplace.
From the ‘featured categories’ on the homepage select Payments & Security.
Scroll down or run a search to find the Mastercard Gateway Module. Click to open the module and select the 'Edition' corresponding to your Magento Edition and the 'Your store version' corresponding to your Magento version.
Click on ‘Add to cart’ and proceed to checkout.
Type-in the required information
and click on ‘Place Order.’
The purchase confirmation page will give you an option to install the purchased package.
Install the package and open a terminal in MacOS or the Command Prompt in Windows Machine. Follow the command line instructions as shown to complete the installation of the package.
Now let’s move on to the backend configuration of the module. To do this, you have to login to the Magento Admin panel and navigate to Store,
Configuration,
Sales, and then select Payment Methods.
When it comes to backend configuration, you can set it for three types of Payment Methods
Hosted Checkout, Hosted Payment Session and Automated Clearing House or ACH. In the first two methods, you can set the configuration for ‘Authorize Only’, which is also known as 'Authorize', and for ‘Authorize and Capture', also known as ‘Pay’.
You can configure 'Authorize Only' in Hosted Checkout for both 3DS and non-3DS cards, by going to the 'Hosted Checkout' section and choosing 'Authorize Only' as the 'Payment Action'. Note that captures for both card types can be processed online or offline. To set up “Authorize and capture" in Hosted Checkout for both 3DS and non-3DS cards, navigate to the ‘Hosted Checkout’ section and select ‘Authorize and Capture’ as the ‘Payment Action’.
To configure ‘Authorize Only’ in the Hosted Payment Session for the three 3DS security levels; 3DS-disabled, 3DS1, and 3DS2; proceed to ‘Hosted Payment Session’ and choose ‘Authorize Only’ as the ‘Payment Action’.
Here, before saving the configuration, ensure that for 3DS-disabled cards the ‘Enable 3-D Secure’ option is set to ‘Disabled’, for 3DS1, it is set to ‘Enabled 3-D Secure’ and for 3DS2, it is set to ‘Enabled EMV 3-D Secure’.
To configure ‘Authorize and Capture’ in the Hosted Payment Session for the three security levels, navigate to ‘Hosted Payment Session’ and choose ‘Authorize and Capture’ as the ‘Payment Action’.
Here also, before saving the configuration, ensure that for 3DS-disabled cards the ‘Enable 3-D Secure’ option is set to ‘Disabled’, for 3DS1,
it is set to ‘Enabled 3-D Secure’ and for 3DS2,
it is set to ‘Enabled EMV 3-D Secure’.
And now, to configure ‘Pay’ in ACH, go to the ‘Automated Clearing House’ section and choose ‘Pay’ as the ‘Payment Action’.
To configure 'Verify and Add Token to Order' in ACH, go to the 'Automated Clearing House (ACH)' section and choose ‘Verify and Add Token to Order’ as the 'Payment Action'. Finally, save the configuration and that’s it. The Mastercard Gateway module is installed and configured successfully, ready for use.


Install the Mastercard Gateway plugin and configure it in the PrestaShop admin panel.
Transcript
Hi, welcome to Mastercard Gateway, your key to seamless payment integration. Today, let’s have a quick and easy walkthrough on installing and configuring the Mastercard Gateway plugin on the PrestaShop platform. Start by downloading the Mastercard Gateway plugin for PrestaShop directly from Fingent's GitHub repository. To download the plugin, navigate to Fingent's GitHub repository. Here, scroll down to the ‘Releases’ section, where you can choose the latest version labeled ‘Latest’ or click on the ‘Releases’ link to see a complete list of all available plugin versions. Inside each version card, you can expand the ‘Assets’ section to view the available files for that version. Find the version you want, then click on the ‘prestashop-mastercard.zip’ file to download it.
Next, it's time to upload the downloaded file. Start by logging in to your PrestaShop Admin Dashboard. Once you're in, go to Modules and select Module Manager. On the upper right-hand side, you'll find the ‘Upload Module’ option. Click on it to start the installation. Next, locate and select the downloaded ‘prestashop-mastercard.zip’ file to initiate the installation. After the installation is complete, click on the ‘Configure’ button to access the configuration settings.
Alternatively, from your PrestaShop Admin Dashboard, go to ‘Modules’ and select ‘Module Manager’. Then, use the ‘Category’ dropdown to select ‘Payment’ and view all available payment options. You can then find the ‘Mastercard Gateway’ module in the list and click on the ‘Configure’ button on the right-hand side to access the configuration page. The plugin offers the ‘Hosted Checkout’ integration method for seamless payment processing. ‘Hosted Checkout’ is a ready-to-use, fully managed payment page from the payment provider, ensuring a secure and hassle-free transaction experience.
With this integration model, you can easily configure settings for both ‘3DS-enabled’ cards which gives enhanced security through 3D Secure authentication, and ‘Non-3DS’ cards for standard payment processing. Toggle on the ‘Enable’ button and set the Payment Model to ‘Purchase’, which ensures that the customer is charged immediately upon completing the transaction.
Alternatively, select the ‘Authorize’ payment model to reserve the payment. You can then manually capture it later through the PrestaShop Admin Panel, giving you greater control over transaction processing. While using the Hosted Checkout Integration Model, you have the flexibility to define the Checkout Interaction model as ‘Embedded’, where the payment form is embedded directly within your website for a seamless checkout experience. Alternatively, you can choose ‘Redirect to Payment Page’, where the customers are redirected to a secure, hosted payment page to complete the transaction. Finally, save the configuration, and that’s it! You have now successfully installed and set up the PrestaShop Mastercard Gateway plugin, ready for use.
